Designio2 Steel Inset Gas Fire

Description
Facts
Options
Tech Specs

Similar in form to the Designio2 Glass inset gas fire, the Designio2 Steel has a clean and contemporary design which perfectly complements the range of 16″ gas fires.

The Designio2 Steel inset gas fire is available in a choice of either stylish bold Graphite or eye-catching Iridium finishes and suitable for both hearth mounting and inbuilt installations further up the wall.

This inset is available with a choice of either Logs or Coal fuel effects and comes with three different control types: Manual control, Slide control or, for the absolute convenience, a Remote control for the ultimate luxury heating experience.

Designio2 Steel Inset Gas Coals Conventional Flue
Efficiency	89%
Heat out put	4.10 kW
Efficiency rating	B
Vent required	No
Manual control	Yes
Slide control	Yes
Remote control	Yes
Opening dimensions	410 x 560 mm (w x h)
Frame Size	519 x 660 mm (w x h)

Designio2 Steel Inset Gas Logs Conventional Flue
Efficiency	84%
Heat out put	3.90 kW
Efficiency rating	C
Vent required	No
Manual control	No
Slide control	Yes
Remote control	Yes
Opening dimensions	410 x 560 mm (w x h)
Frame Size	519 x 660 mm (w x h)

Designio2 Steel Inset Gas Coals Balanced Flue
Efficiency	86%
Heat out put	3.30 kW
Efficiency rating	C
Vent required	No
Manual control	Yes
Slide control	Yes
Remote control	Yes
Opening dimensions	420 x 560 mm (w x h)
Frame Size	519 x 660 mm (w x h)

Designio2 Steel Inset Gas Logs Balanced Flue
Efficiency	86%
Heat out put	3.40 kW
Efficiency rating	C
Vent required	No
Manual control	No
Slide control	Yes
Remote control	Yes
Opening dimensions	420 x 560 mm (w x h)
Frame Size	519 x 660 mm (w x h)
